Connection
This chapter provides all necessary information of the peripheral's connections,
switches and indicators. Always power off the board before you install the peripherals.
3-1 List of Connectors
CPI1 : DC 12V-IN Power Jack
CPI12 :DC-in 1x2 pin (2.0mm) Wafer connector
CPI11 : DC-In 2x2 pin (4.20mm) Wafer connector (Option)
CBT1 : 3V Battery 1x2pin(1.25mm)Wafer (Option)
BAT1 : 3V Battery hold 2pin
CPO1 : +12V/+5V power output 4 pin (2.0mm) Wafer
CFP1 : FP port 2x5 pin (2.0mm) Wafer
CG1 : VGA DB15 connector (Option)
CG11 : VGA port 2x5 pin (2.0mm) Wafer
DVI1 : DVI-D port connector
HDMI1 : HDMI 1.3a port Type A connector (Option)
LVDS1 : LVDS 18 Bits 2x10 pin (1.25mm) connector
CPP1 : Panel inverter power connector 1x5 pin (2.0mm) Wafer
CT1 : Touch screen device 2x5 pin (2.0mm) Wafer
CA1 : Line-out phone jack
CA3 : Line-out/Line-in/Mic-in 2x5 pin (2.0mm) Wafer
CAR1,CAL1 : Two Channel Speak out ports 2pin (2.0mm) Wafer (Option)
CC1 : COM1 DB9pin connector (Option)
CC2 : COM2 2x5 pin (2.0mm) Wafer
CIO1 : One DIO 2x5 pin (2.0mm) Wafer
2
CO1 : I C 4pin (1.25mm) Wafer
CL1 : LAN port RJ45
CL1 : LAN port 2x4pin (2.0mm) Wafer (Option)
CU1 : USB1 port Type A connector (Option)
CU11 : USB1 port 4pin(1.25mm) Wafer
