4-4 Standard CMOS Features

The items in Standard CMOS Setup Menu are divided into several categories.
Each category includes none, one or more than one setup items. Use the arrow keys to
highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want to
modify with this item.
Phoenix
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Channel 0
IDE Channel 1
Video
Halt On
Base Memory
Extended Memory
Total Memory
↑↓→← :Move Enter:Select +/
F5:Previous Values
IDE Primary/Secondary Master
Press PgUp/<+> or PgDn/<-> to select Manual, None, Auto type. Note that the specifications
of your drive must match with the drive table. The hard disk will not work properly if you enter
improper information for this category. If your hard disk drive type is not matched or listed,
you can use Manual to define your own drive type manually. If you select Manual, related
information is asked to be entered to the following items. Enter the information directly from the
keyboard. This information should be provided in the documentation from your hard disk vendor
or the system manufacturer.
Video
The setting controls the type of video adapter used for the primary monitor of the system.
Settings are: EGA/VGA (default), CGA 40, CGA 80 and Mono.
Halt On
The setting determines whether the system will stop if an error is detected at boot.
Settings are: All Errors:
No Errors (default):
All, But Keyboard:
AwardBIOS CMOS Setup Utility
-
Standard CMOS Features
Tue, Nov 6 2012
0 : 0 : 0
Master
[ None ]
Master [ None ]
[EGA/VGA]
[ No Errors]
640K
1038336K
1039360K
- /PU/PD:Value F10:Save ESC:Exit F1:General Help
F6:Fail-Safe Defaults
The system stops when any error is detected.
The system doesn't stop for any detected error.
The system doesn't stop for a keyboard error.
Menu Level >
Change the day, month,
year and century
F7:Optimized Defaults
44
Item Help
