3-6-2 IO Device: F75111 under Windows

The Sample code source you can download from

Source file: F75111_DIOSrc.rar

http://tprd.info/lexwiki/index.php/IO_Device:F75111

Binary file: F75111_DemoBin.rar

USERNAME & PASSWORD: sf

How to use this Demo Application

1. Press the "Start" button to test DIO function

2. Press the "Enable" button to test WDT function

3. Press the "Disable" button to disable WDT

4. Check the "Enable Loop" box and press "Enable" to do WDT loop test

5. Press "Install WDT" to set the system to autorun this application when booting,

press again to remove this application when booting.

6. If WDT enable, system icon will be

. if disable, system icon will be
