4-7 Integrated Peripherals

OnChip IDE Device

Super IO Device
USB Device Setting
↑↓→← :Move
F5:Previous Values
OnChip IDE Device Function
Please refer to section 4-7-1
Super IO Device Function
Please refer to section 4-7-2
USB Device Setting
Please refer to section 4-7-3
4-7-1 OnChip IDE Device
IDE HDD Block Mode
IDE DMA transfer access
IDE Primary Master PIO
IDE Primary Master UDMA
On-Chip Secondary PCI IDE
IDE Secondary Master PIO
IDE Secondary Master UDMA
SATA Mode
LEGACY Mode Support
↑↓→← :Move
F5:Previous Values
IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or multiple sector read/write. If
your IDE hard drive supports block mode (most new drives do), select Enabled for automatic
detection of the optimal number of block read/writes per sector the drive can support. The
settings are: Disabled, Enabled (default).
Phoenix-AwardBIOS CMOS Setup Utility
Integrated Peripherals
Enter:Select +/ - /PU/PD:Value
F6: Fail-Safe Defaults
Phoenix-AwardBIOS CMOS Setup Utility
Enter:Select +/ - /PU/PD:Value
F6: Fail-Safe Defaults
[ Press Enter ]
[ Press Enter ]
[ Press Enter ]
F10:Save
OnChip IDE Device
[ Enabled ]
Enabled ]
[
[ Auto ]
[ Auto ]
[ Enabled ]
[ Auto ]
[ Auto ]
[ IDE ]
[ Disabled ]
F10:Save
50
Item Help
Menu Level >
ESC:Exit F1:General Help
F7:Optimized Defaults
Item Help
Menu Level >>
ESC:Exit F1:General Help
F7:Optimized Defaults
