(GNSS) @open sky
Warm start
@open sky
Hot start
@open sky
Accuracy
CEP-50
(GNSS)
NOTES
Tracking sensitivity: the lowest GNSS signal value at the antenna port on which the module can keep
1.
on positioning for 3 minutes.
Reacquisition sensitivity: the lowest GNSS signal value at the antenna port on which the module can
2.
fix position again within 3 minutes after loss of lock.
Cold start sensitivity: the lowest GNSS signal value at the antenna port on which the module fixes
3.
position within 3 minutes after executing cold start command.

4.5. ESD Characteristics

The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject
to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and
packaging procedures must be applied throughout the processing, handling and operation of any
application that incorporates the module.
The following table shows the module electrostatic discharge characteristics.
Table 22: Electrostatic Discharge Characteristics
Tested Points
VBAT, GND
Antenna Interfaces
Other Interfaces
XTRA enabled
Autonomous
XTRA enabled
Autonomous
XTRA enabled
Autonomous
@open sky
Contact Discharge
± 5
± 4
± 0.5
TBD
TBD
TBD
TBD
TBD
TBD
Air Discharge
± 10
± 8
± 1
s
s
s
s
s
m
Unit
kV
kV
kV
33 / 50
