4.6. Current Consumption

The following table shows the current consumption of the EP06-A.
Table 23: EP06-A Current Consumption
Parameter Description
Sleep state
Idle state
WCDMA data WCDMA B2 HSDPA CH9400 @23.5dBm
Conditions
AT+CFUN=0 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=128 (USB disconnected)
WCDMA PF=256 (USB disconnected)
WCDMA PF=512 (USB disconnected)
LTE-FDD PF=32 (USB disconnected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=128 (USB disconnected)
LTE-FDD PF=256 (USB disconnected)
LTE-TDD PF=32 (USB disconnected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=128 (USB disconnected)
LTE-TDD PF=256 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=64 (USB connected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=64 (USB connected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=64 (USB connected)
Typ. Unit
1.88 mA
2.4 mA
2.29 mA
2.29 mA
2.28 mA
3.5 mA
3.47 mA
3.5 mA
3.49 mA
3.67 mA
3.6 mA
3.2 mA
3.54 mA
21.2 mA
31.3 mA
22.7 mA
31.1 mA
23.9 mA
31.2 mA
673.7 mA
