Technical Information

Dimensions

Wheel flange-spigot diameter Ø 180 mm - BC Ø 210 mm
84[3.31]
C:
G 3/4; 17 mm [0.66 in] deep
D: Drain connection G 1/4; 12 mm [0.47 in] deep
E:
M10; 17 mm [0.66 in] deep
F:
M14 × 1.5
16
TMTHW Orbital Motors
Size
Weight
Output shaft
Mounting flange
L1327341 • Rev BA • April 2015
Ø172[6.77]
Ø92.9[3.66]
Ø92.7[3.65]
max 146[5.75]
Ø180.0 [7.09]
Ø179.8 [7.08]
10x Ø14.2[0.56]
max 195.4[7.69]
3
315-800 cm
34-38 kg
F180/5xM14 BC ø140/PD.ø92.8
Wheel 10x ø14 BC ø210/PD ø180
F
P301 565
