Function Diagrams; Tmthw 315 - Danfoss TMTHW Series Technical Information

Technical Information

Function diagrams

TMTHW 315

12
TMTHW Orbital Motors
Explanation of function diagram use, basis and conditions can be found under
and torque
[blue] Continuous range
[pink] Intermittent range (max. 10% operation every minute)
Intermittent pressure drop and oil flow must not occur simultaneously.
VMP 50
Nm
lbf• in
1750
15 000
1500
20kW
5kW
10kW
N=2.5kW
1250
10 000
1000
750
5 000
500
250
0 0
0 50 100
L1327341 • Rev BA • April 2015
40kW
30kW
50kW
η
=80%
t
75%
150 200 250 300 350
Speed and torque
60kW
75kW
70%
η
=60%
t
400 450 500 550 600
Speed
min
-1
(rpm)
P301 551
