Danfoss TMTHW Series Technical Information page 18

Technical Information
Dimensions
C:
G 3/4; 17 mm [0.66 in] deep
D: Drain connection G 1/4; 12 mm [0.47 in] deep
E:
M10; 17 mm [0.66 in] deep
F:
M16 × 1.5
18
TMTHW Orbital Motors
Size
Weight
Output shaft
Mounting flange
TMTHW dimensions
Size L
MAX
3
400-800 cm
mm [in]
TMTHW 400 139 [5.47]
TMTHW 500 147.6 [5.81]
TMTHW 630 161.6 [6.36]
TMTHW 800 161.6 [6.36]
L1327341 • Rev BA • April 2015
3
400-800 cm
42.1-44.5 kg
F200/6xM16 BC ø170/PD.ø130
Wheel 8x ø17.5 BC ø265/PD ø224
L L
1 2
mm [in] mm [in]
120.8 [4.76] 109.8 [4.32]
129.4 [5.09] 118.4 [4.66]
143.4 [5.65] 132.4 [5.21]
143.4 [5.65] 132.4 [5.21]
L Weight
3
mm [in] kg [lb]
95.3 [3.75] 42.1 [92.81]
103.9 [4.09] 43.0 [94.80]
117.9 [4.64] 44.5 [98.11]
117.9 [4.64] 44.5 [98.11]
