Operation
6.1 Times
Verification of response times in the case of safety circuits
When safety equipment is commissioned, steps must be taken to verify that a safety-related
output will switch off within a maximum permissible response time if the input signal changes
at the relevant input.
To provide this verification, you must calculate the total response time of the application you
have configured.
Note
Note that the results of calculating the response time affect the level of safety and affect the
overall design of the system.
Response time up to the switch-off procedure after expiry of the set start override time
The maximum response time up to detection of a violation of the upper/lower limit depends
on the selected parameters. The lower the set values, the longer the device requires to
detect the pending fault.
To achieve a faster response time, encoders or gear wheels that supply several pulses per
revolution can be used (e.g. encoders with 32 pulses). This reduces the time 1 / f
the factor of the number of pulses of the encoder or the number of teeth on the gear wheel.
The following applies in general: t
e.g. under-speed in setup mode to be checked 120 rpm = 2 Hz
with initiators (1 pulse/rev.): t
with encoder with number of pulses = 32: t
f = set frequency threshold or frequency of the applied measuring signal (e.g. under-
frequency in setup mode)
t
Response
ms)
Indication on the display
In the normal operating mode, all set values can be checked at any time by pressing the
"Up" or "Down" key.
In addition, the current speed is indicated by initiator 1 or by the encoder. However, this
speed does not correspond to the accuracy of the device and is used exclusively for
diagnostics purposes!
40
Switch-off_max
= internal response time following detection of the switch-off frequency (max. 150
= 1 : f + t
Switch-off_max
Response
= 1 : 2 Hz + 150 ms = 650 ms
= 1 : (2 Hz x 32) + 150 ms = 166 ms
Switch-off_max
System Manual, 01/2011, 926246402000 DS 02
threshold
3TK2810-1 safety-related speed monitor
