Operating Range - SMC Networks CYP Series Technical Data Manual

Proper Auto Switch Mounting Position Detection
(Detedtion at stroke end)
A
Proper Auto Switch Mounting Position
Auto switch
model
Cylinder model
CYP15
CYP32
Note) Adjust the auto switch after confirming the operating conditions in the actual setting.
Mounting of Auto Switch
When mounting auto switches, they should be
inserted into the cylinder's auto switch
installation groove from the direction shown
in the drawing on the right. After setting
in the mounting position, use a flat
head watchmaker's screwdriver
to tighten the auto switch
mounting screw which is
included.
Note) When tightening the auto switch mounting screw (included with the auto switch), use a watchmaker's
screwdriver with a handle about 5 to 6 mm in diameter. The tightening torque should be
approximately 0.05 to 0.1 N⋅m.
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
A
D-Y5
D-Z7 D-Y7 W
D-Y6
D-Z80
D-Y7 WV D-Y7P
D-Y7PV
24.5
33
Auto switch
Auto switch mounting screw
(included with auto switch)
Clean Rodless Cylinder
B
B
D-Y5
D-Z7 D-Y7 W
D-Y6
D-Z80 D-Y7 WV
D-Y7P
D-Y7PV
93.5
122
Watchmaker's
screwdriver
Series

Operating Range

Auto switch
model
D-Z7
D-Z80
Cylinder model
CYP15 6.5
CYP32 9.5
Note) Operating ranges are standards including
hysteresis, and are not guaranteed. (variations on
the order of ±30%)
Large variations may occur depending on the
surrounding environment.
CYP
D-Y7 W
D-Y7 WV
D-Y5
D-Y6
D-Y7P
D-Y7PV
2.5
3
CY3B
CY3R
CY1S
CY1L
CY1H
CY1F
CYP
D-„
-X„
Individual
-X„
Technical
data
1259
