Clean Rodless Cylinder
CYP
Series
ø15, ø32
CY3B
CY3R
CY1S
CY1L
CY1H
CY1F
CYP
agnetically coupled rodless cylinder for transfer in clean environments.
D-„
-X„
Individual
-X„
Technical
data
1249
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Advertisement
Table of Contents
Related Manuals for SMC Networks CYP Series
Summary of Contents for SMC Networks CYP Series
- Page 1 Clean Rodless Cylinder Series ø15, ø32 CY3B CY3R CY1S CY1L CY1H CY1F agnetically coupled rodless cylinder for transfer in clean environments. D-„ -X„ Individual -X„ Technical data 1249 Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com...
- Page 2 A magnetically coupled rodless cylinder that can be used for transfer in clean environments Shock-free ow particle generation: 1/20 ong stroke A sine cushion is used at the end of the stroke. Smooth acceleration and deceleration are possible (compared to previous series) at 5 m/s or less.
-
Page 3: Model Selection
Series Model Selection 1 Caution on Design (1) The load mass allowable moment differs depending on the workpiece mounting method, cylinder mounting orientation and piston speed. In making a determination of usability, do not allow the sum (Σαn) of the load factors (αn) for each mass and moment to exceed “1”. α... - Page 4 Series Model Selection 2 Selection Calculation α α The selection calculation finds the load factors ( n) of the items below, where the total (Σ n) does not exceed 1. Σ α α α α ≤ 1 α Item Load factor Note α...
-
Page 5: Vertical Operation
Series Model Selection 3 Caution on Design (2) Table Deflection Note) Table deflection due to Table deflection due to Table deflection due to pitch moment load roll moment load yaw moment load Guide central axis Guide central axis F x L F x L F x L Note) Displacement of Section A when force acts on Section F... -
Page 6: How To Order
Clean Rodless Cylinder Series ø15, ø32 How to Order CYP 15 Y7BW Number of auto switches Clean room rodless cylinder 2 pcs. 1 pc. “n” pcs. Bore size 15 mm Auto switch 32 mm Without auto switch (Built-in magnet) For the applicable auto switch model, refer to the table below. -
Page 7: Specifications
Series Specifications Bore size (mm) Note 1) Fluid Air/Inert gas Action Double acting Proof pressure 0.5MPa Operating pressure range 0.05 to 0.3MPa Ambient and fluid temperature –10 to 60°C Note 2) Piston speed (Max.) 50 to 300mm/s Lubrication Not required (Non-lube) ±1mm on each side (±2mm total) Stroke adjustment Cushion... - Page 8 Series Clean Rodless Cylinder Construction CYP15 CYP32 CY3B CY3R CY1S CY1L CY1H CY1F Component Parts Description Material Note Description Material Note Magnet A — Cylinder tube gasket Piston side yoke Rolled steel plate Zinc chromated O-ring O-ring ø15: Electroless nickel Piston Brass/Aluminum alloy plated, ø32: Chromated...
- Page 9 Series Dimensions ø Depth Thread depth øB 4 x Counterbore dia øLD Counterbore depth Guide central axis depth Stroke Stroke Note 3) Stroke adjustment screw (inner cover) Plug Plug (port c)] (port e)] Plug Operating direction (port a) (port g)] Note 2) Note 2) (port b)
-
Page 10: Operating Range
Series Clean Rodless Cylinder Proper Auto Switch Mounting Position Detection Operating Range (Detedtion at stroke end) D-Y7 W Auto switch D-Y7 WV model D-Z7 D-Y5 D-Y6 D-Z80 D-Y7P Cylinder model D-Y7PV CYP15 CYP32 Note) Operating ranges are standards including hysteresis, and are not guaranteed. (variations on the order of ±30%) Large variations may occur depending on the surrounding environment. -
Page 11: Operation
Series Specific Product Precautions 1 Be sure to read before handing. Refer to front matters 54 and 55 for Safety Instructions and pages 3 to 11 for Actuator and Auto Switch Precautions. Handling Operation Caution Caution 1. Open the inner package of the double packaged 1. -
Page 12: Speed Adjustment
Series Specific Product Precautions 2 Be sure to read before handing. Refer to front matters 54 and 55 for Safety Instructions and pages 3 to 11 for Actuator and Auto Switch Precautions. Speed Adjustment Cushion Effect (Sine Cushion) and Stroke Adjustment Caution Caution 1. -
Page 13: Maintenance
Series Specific Product Precautions 3 Be sure to read before handing. Refer to front matters 54 and 55 for Safety Instructions and pages 3 to 11 for Actuator and Auto Switch Precautions. Maintenance Particulate Generation Characteristics Caution Caution 1. Never disassemble the cylinder tube or linear guide, 1.
