Air cylinder for transfer
in vacuum environments (1.3 x 10
Rodless Cylinder for Vacuum
Series
Simplifies and reduces
the size of equipment
-4
Pa)
Since the cylinder can be installed inside a vacuum
chamber, it contributes to simplifying
and reducing the size of a transfer system.
CAT.ES20-158
A
CYV
ø15, ø32
Vacuum chamber
(Transfer unit)
Series CYV
(Conceptual drawing)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CYV Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks CYV Series

  • Page 1 CAT.ES20-158 Rodless Cylinder for Vacuum Series ø15, ø32 Air cylinder for transfer Simplifies and reduces the size of equipment in vacuum environments (1.3 x 10 Since the cylinder can be installed inside a vacuum chamber, it contributes to simplifying and reducing the size of a transfer system. Vacuum chamber (Transfer unit) Series CYV...
  • Page 2 Air cylinder for transfer Rodless Cylinder for Vacuum Series Low particulate generation ø15, ø32 Average particle generation (particles >0.1 µ) is 0.1 particles/cycle. (Atmospheric conditions) Note 1) This data indicates deterioration with age of the average number of particles per operation under the following test conditions. <Test conditions>...
  • Page 3 in vacuum environments (1.3 x 10 -⁴ Pa) Carefully designed for low particulate generation, low leakage, and low outgassing. Low leakage ⁷ Pa⋅m ³ /sec ⁷ Pa⋅m ³ /sec 1.3 x 10 1.3 x 10 Leakage: or less (at normal temperatures, excluding gas permeation) ⁷...
  • Page 4: How To Order

    Rodless Cylinder for Vacuum Series How to Order CYV 15 Rodless cylinder for vacuum Bore size Standard stroke 15mm Bore size (mm) Standard stroke (mm) 32mm 100, 150, 200, 250 15, 32 300, 350, 400, 450 500, 600, 700 Specifications Bore size (mm) - ⁴...
  • Page 5 Series Rodless Cylinder for Vacuum Construction CYV15 Section E-E' CYV32 Parts list Description Material Description Material Note Note Magnet A Aluminum chromated Aluminum alloy Electroless nickel plated Rare earth magnet Inner cover Piston side yoke Zinc chromated Fluoro rubber Rolled steel plate Cylinder tube gasket Brass/ Electroless nickel...
  • Page 6 Series Dimensions 4-Counter øE øB bore dia. Depth øLD Counter bore Thread depth depth depth + Stroke + Stroke Stroke adjustment screw (inner cover) øTB 2-Counter bore dia. Depth Thread depth Counter bore depth (from counter bore surface) Note) Inner cover holding screw (mm) Model +0.030...
  • Page 7: Model Selection

    Series Model Selection 1 Design Parameters 1 The allowable load mass moment differs depending on the work piece mounting method, cylinder mounting orientation and piston speed. α α To determine whether or not the cylinder can be operated, do not allow the sum (Σ n) of the load factors ( n ) for each mass and moment to exceed "1".
  • Page 8 Series Model Selection 2 Selection Calculation α α The selection calculation finds the load factors ( n) of the items below, where the total (Σ n) does not exceed "1". α α α α Σ ≤ 1 α Item Note Load factor α...
  • Page 9 Series Model Selection 3 Design Parameters 2 Note) Table Deflection Table deflection due to pitch moment load Table deflection due to roll moment load Table deflection due to yaw moment load Central axis of guide Central axis of guide F x L F x L F x L Note) Deflection: Displacement of point A when...
  • Page 10: Safety Instructions

    Series Safety Instructions These safety instructions are intended to prevent a hazardous situation and/or equipment damage. These instructions indicate the level of potential hazard by a label of "Caution", "Warning" or "Danger". To ensure safety, be sure to Note 1) Note 2) observe ISO 4414 , JIS B 8370...
  • Page 11 Series Actuator Precautions 1 Be sure to read before handling. Design Selection Warning Warning 1. There is a danger of sudden action by air cylinders 1. Confirm the specifications. if sliding parts of machinery are twisted, etc., and The products advertised in this catalog are designed only for changes in forces occur.
  • Page 12 Series Actuator Precautions 2 Be sure to read before handling. Air Supply Operating Environment Warning Warning 1. Use clean air. 1. Do not use in environments where there is a danger of corrosion. Do not use compressed air including chemicals, synthetic oils containing organic solvents, salt or corrosive gases, etc., as it Refer to the construction drawings regarding cylinder can cause damage or malfunction.
  • Page 13: Specific Product Precautions

    Series Specific Product Precautions 1 Be sure to read before handling. Handling Operation Caution Caution 1. Open the inner package of the double packaged 2. When used for vertical operation, take precautions clean series product inside a clean room or other against possible dropping due to separation of the clean environment.
  • Page 14 Series Specific Product Precautions 2 Be sure to read before handling. Speed Adjustment Maintenance Caution Caution 1. A speed controller for clean room use is recommend- 1. Never disassemble the cylinder tube or linear guide, ed for speed adjustment. etc. 2.
  • Page 16 SMC'S GLOBAL MANUFACTURING, DISTRIBUTION AND SERVICE NETWORK EUROPE EUROPE NORTH AMERICA SLOVENIA AUSTRIA CANADA SMC Slovenia d.o.o. SMC Pneumatik GmbH SMC Pneumatics (Canada) Ltd. SPAIN/PORTUGAL CZECH MEXICO SMC Czech s.r.o. SMC España, S.A. SMC Corporation (Mexico) S.A. de C.V. SWEDEN DENMARK SMC Pneumatics Sweden AB SMC Pneumatics, Inc.
