Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Page 4
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
4/11 1. Handling 1. Cylinder is supplied in a double clean package. When opening the internal package, be sure to open it in a clean room or clean atmosphere. 2. Do not touch the cylinder with bare hands when installing a cylinder to an application. It may affect the discharge gas characteristics.
Page 6
5/11 3. Two optional ways of mounting are available when mounting the cylinder with bolts. Select the one which is applicable to the equipment specifications. (See figure 2) Figure 2. Bolt mounting 4. As the slide table is fixed with a precision bearing, do not apply a strong impact or excessive moment on the slide table when mounting works.
6/11 3. Piping 1. The compressed air supply inlet of the cylinder has a unified thread. For this vacuum rodless cylinder, use fitting for vacuum (with O-ring) commercially available.(Table 1) Table 1 Example of applicable fitting: Male connector (O-ring parallel thread) (Made by Swegelok) Cylinder Fitting thread size for Example of...
7/11 7. Be sure to operate the cylinder in a pressure environment between atmospheric pressure -4 and 1.3×10 Pa (ABS).If it is operated in a lower pressure environment, the grease applied to the guide will evaporate too much, which may affect the endurance and contaminate the chamber.
8/11 (Remove all the operating air, and take measures to deal with the residual pressure and cylinder-drop for a safety measure before the adjustment. ) 【Procedure】 Loosen the inner cover fixing screw with a hexagon wrench. Turn the stroke adjusting screw (inner cover) with the hexagon wrench clockwise and counterclockwise, move the inner cover to back and front, and mate the position with the mechanical stopper.
9/11 8. Feature to prevent particle generation To maintain the grade of particle generation, restrict the operating cycle up to 1,000,000 cycles, and running distance up to 200km as a standard. If it exceeds the recommended rate, the linear guide doesn’t move smoothly, and deteriorates the feature to prevent particle generation. Replace the cylinder in a proper timing depending on the cylinder condition.
