Mocka Kennedy Three Drawer Assembly Instructions Manual page 7

Kennedy Three Drawer
Assembly Instructions
11
C
C
10
11
Insert 15x bolts (C) into panels [10], [11] and [12]. Attach 3x plug (L) to
panels [10], [11] and [12] and secure with 3x screw (E). Tighten with a
screwdriver.
mocka.co.nz | mocka.com.au
E
C
L
C
C
12
12
13
D
D
10
11
12
Attach panel [13] ,[14] and [17] to front panel [10], [11] and [12] using 15x
locking nuts (D).Tighten with a screwdriver.
17
D
14
D
D
7
