Mocka Kennedy Three Drawer Assembly Instructions Manual page 2

Kennedy Three Drawer
Assembly Instructions
1
C
C
C
Insert 6x bolts (C) into panel [1]. Attach panel [5] to panel [1] using
3x screws (M). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
C
C
M
M
5
M
1
2
C
The round head
is aligned with the
direction of the arrow
C
C
Attach 1x bracket (J) to panel [6] and secure with 2x screws (E). Tighten
with a screwdriver and attach 1x cover (K) as shown. Insert 6x bolts (C)
into panel [1]. Attach 1x bracket (J) to panel [4] and secure with 2x screws
(E).Tighten with a screwdriver and attach 1x cover (K) as shown.
E
E
K
J
J
E E
J
C
6 x2
E
E
J
C
4
C
C
2
