Mocka Kennedy Three Drawer Assembly Instructions Manual page 5

Kennedy Three Drawer
Assembly Instructions
7
T
9
T
front
back
Attach a leg bracket (P) to each leg [9] using 2x screws (R) and 1x long
bolt (Q). Tighten with the allen key (U) and screwdriver. Attach the leg
panels [9] to panel [4] using 16x bolts (S) and 16x washers (T) as shown.
Tighten with the allen key (U).
mocka.co.nz | mocka.com.au
T
S
T
9
S
9
S
T S
T
S
U
9
S
R
P
R
Q
front
U
8
9
2
x4
Attach 3x slide rails (G) to panel [3] and secure with 9x screws (E).
Attach 3x slide rails (F) to panel [2] and secure with 9x screws (E).
Tighten with a screwdriver.
E
CR
G
E
E E
E
E
F
E
F
E
F
G
E
E
G
3
E
G
E
5
