Kennedy Buffet
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
C
dowel
bolt
locking
x12
x12
nut x12
I
J
K
bracket
long
hinge
x4
bolt x4
x4
WARNING:
Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
mocka.co.nz | mocka.com.au
D
E
F
screw
bracket
cover
x30
x2
x2
L
M
N
shelf
wedge
allen
screw
plug x8
x6
key x1
Hardware Supplied
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
H
G
plug
bolt
x2
x16
O
P
Q
screw
washer
x8
x6
x16
V
W
X
safety
screw
wall
x1
strap x1
anchor
x1
Wall Strap
*We recommend using a Flathead screwdriver to tighten
all locking nuts 100% before rst use.
Please clear any loose wood from the locking nut holes
before inserting the nut to ensure it locks 100%.
Y
Z
wall
washer
screw
x2
x1
1
Advertisement
Table of Contents
Related Manuals for Mocka Kennedy Buffet
Summary of Contents for Mocka Kennedy Buffet
- Page 1 Kennedy Buffet Assembly Instructions Thank you for your purchase. Please follow the instructions below for correct assembly. safety screw wall wall washer screw bracket cover dowel bolt locking plug bolt strap x1 anchor screw nut x12 Wall Strap shelf bracket...
- Page 2 Kennedy Buffet Assembly Instructions Insert 6x bolts (B) into the underside of panel [1]. Attach 2x brackets (E) Attach panels [3], [4] and [5] to panel [1] using 6x dowels (A) and secure as shown and secure with 4x screws (D). Tighten with a screwdriver.
- Page 3 Kennedy Buffet Assembly Instructions Slide panel [7] down along the grooves between the side panels to Insert 6x bolts (B) into panel [2]. form the back of the unit. mocka.co.nz | mocka.com.au...
- Page 4 Kennedy Buffet Assembly Instructions front back Front Attach panel [2] to the main unit using 6x dowels (A) and 4x locking Attach a leg bracket (I) to each leg [10] using 2x screws (O) and 1x long nuts (C). Tighten with a screwdriver.
- Page 5 Kennedy Buffet Jolt Wardrobe Assembly Instructions ASSEMBLY INSTRUCTIONS Attach 2x hinges (K) and 1x plug (G) to panel [8] and secure with 5x Insert 8x shelf plugs (L) into the cabinet as shown. screws (D). Attach 2x hinges (K) and 1x plug (G) to panel [9] and secure with 5x screws (D).
- Page 6 Kennedy Buffet Assembly Instructions NOTE: If the doors are uneven or there is a gap in the middle, loosen or tighten the screw on the door hinge until they are sitting flush. insert shelf panels [6] into the cabinet, ensuring they rest level on the Attach door panels [8] and [9] to the main unit as shown, using 4x small shelf plugs (L).
- Page 7 Kennedy Buffet Assembly Instructions Wall Mount strap wall plug screw Attach 6x wedges (M) to the corners of the back panel and secure with Once assembled lift furniture into place, do not drag. Use a drill to create 6x screws (P). Attach 1x safety strap (Y) to the top of the back side of a small hole lining up with the top of the safety strap (V).
