2.1 Pedestrian Access Travel Time
This sets the time the gate/door opens when a pedestrian access input is activated.
2.2 Pedestrian Access Auto Close Time
This sets the countdown timer for automatically closing the gate/door when a pedestrian access input is
activated.
2.3 Pedestrian Access Auto Close Time with PE Trigger
This sets the countdown timer for automatically closing the gate/door when a photoelectric beam is
triggered and pedestrian access input is activated.
2.4 Pedestrian Access Auto Close on Sequential Obstructions
If the pedestrian access auto close is set and the gate/door closes onto an object the gate/door will stop
and reopen. This setting sets the amount of times the gate/door will try to auto close. After trying for the
set limit the gate/door will remain open.
2.5 Pedestrian Access with Hold Gate
If the pedestrian access hold gate is ON and the Pedestrian access input is permanently activated the
gate will remain open in the pedestrian access position. Open input, Close input, Push Button input and
remote controls are disable. Used in Fire Exit applications.
Menu 3 – Input Functions
This allows you to change the Polarity of photoelectric beam, stop and limit switch inputs.
Menu No.
3.1 Photoelectric Beam Polarity
3.2 Limit Switch Polarity
3.3 Stop Input Polarity
3.4* Auxiliary Input (M2 Open Limit Terminal)
3.5 Exit
* 3.4: This option is only available when used for single gate mode
Motor 2 Open Limit terminal can be used to wire Elsema's safety bump strip on a single gate application.
14
Input Functions
Double Gate & Door Controller
Factory Adjustable
Default
Normally Closed /
Normally Closed
Normally Open
Normally Closed /
Normally Closed
Normally Open
Normally Open /
Normally Open
Normally Closed
Disable /
Disabled
Safety Bump Strip
with Eclipse Operating System (EOS)
®
