1.4 Auto Close after Power Restored

If the gate/door is open in any position and then there is a power failure, when power is reconnected the
gate/door will close with this timer.

1.5 Normal Auto Close on Sequential Obstructions

If the normal auto close is set and the gate/door closes onto an object the gate/door will stop and reopen.
This setting sets the amount of times the gate/door will try to auto close. After trying for the set limit the
gate/door will remain open.

1.6 Auto Close Only when Fully Opened

The auto close timer will not time out unless the gates/doors are fully opened.

1.7 Auto Close Only at Night

When the DNS is connected and the sensitivity (Menu 16.8) is set correctly the auto close will only work at
night.
Menu 2 – Pedestrian Access
There are several types of Pedestrian access modes. Pedestrian access opens the gate/door for a short
time to allow someone to walk through the gate/door but does not allow a vehicle access.
Elsema Pty Ltd recommends a photoelectric beam should be connected to the control card when any of
the auto closes options are used.
Menu No.
2.1 Pedestrian Access Travel Time
2.2 Pedestrian Access Auto Close Time
2.3 Pedestrian Access Auto Close Time with PE trigger
2.4 Pedestrian Access Auto Close on Sequential Obstructions
2.5 Pedestrian Access with Hold Gate
2.6 Exit
www.elsema.com
Pedestrian Access Features Factory Adjustable
Default
3 seconds 3 - 20 seconds
Off 0 - 60 seconds
Off 0 - 60 seconds
Min = Off,
2
Max = 5
Off Off/On
