LAUNCH
2
LCD
POWER key
3
Charging LED
4
5V Charging port
5
3.2 Technical Specifications
• Screen: 5 " touch screen
• RAM: 1G
• ROM: 8GB
• Battery: 6000mAh rechargeable Li-battery
• OBDII input voltage range: 9~18V
• Charging via:
• DC 5V charging cable or
• Diagnostic cable through connection to vehicle's DLC
• Dimension: 3.7 " x 8.5 " x 1.3 " (95mm x 217mm x 33mm)
• Net weight: 20oz (<560g)
• Working temperature: -10 to 50°C (14 to 122 F°)
• Storage temperature: -20 to 70°C (-4 to 158 F°)
8
Indicates test results.
• In Off mode, press it for about 5 seconds to turn
the handset on.
• In On mode:
• Press it to activate the LCD if the LCD is off.
• Press it to turn off the LCD if the LCD lights
up.
• Press it for 3 seconds to turn it off.
Red means Charging and Green means Fully
charged.
To connect to external DC power for charging the
tool.
