- Page 1 CRT 7 Series Quick Start Guide WARNING: Read this material before using this product. Failure to do so can result in serious injury. For more detailed operations, refer to the In-app User Manual.
-
Page 2: Safety Precautions
Safety Precautions Before using this test equipment, please read the following Automotive batteries contain sulfuric acid that is harmful Ÿ safety information carefully. to skin. In operation, direct contact with the automotive batteries should be avoided. Keep the ignition sources Always perform automotive testing in a safe environment. -
Page 3: Components And Controls
Components & Controls 1. Charging port Charge the tool. TPMS sensor slot Insert the sensor into the slot. 3. TPMS antenna Display screen 5. Camera flash 6. Adjustable stand Flip it out to any angle and work comfortable at your desk, or hang it on steering wheel. -
Page 4: Accessory Included
*Note: If the battery remains unused for a long period of time or the battery is completely discharged, it is normal that the tool will not Blank LAUNCH RF Sensor x 4 power on while being charged. Please charge it for a period of 5... -
Page 5: Register & Update
Register & Update The first time you use this tool, you will need to make some system settings and keep the diagnostic software updated with the latest version. Follow the steps below to proceed. Tap “Start” on Welcome screen Select system language Select time zone WLAN setup *Note: After completing this step, the system will... - Page 6 Job Menu TPMS: OE Inquiry: Perform various TPMS operations. It mainly includes TPMS Inquires the original OE part number of the sensor. sensor activation, programming, relearning and TPMS Upgrade: diagnostics functions. Update the diagnostic software and APK. Diagnose: Settings: Diagnose a vehicle manually. It supports basic diagnostic functions for full vehicle systems of the most prevailing Make some system adjustment and setting of the tool to your vehicle models.
- Page 7 Connection & Diagnostics 1). Make sure that the vehicle battery voltage range is 11- If the DLC cannot be found, refer to the vehicle's service 14Volts and the ignition is turned off. manual for the location. 3). Connect one end of the diagnostic cable to the DB15 diagnostic connector of the tool, and the other end to the vehicle’s DLC (Data Link Connector) port.
- Page 8 2. Program Sensor Select vehicle model & year This function allows users to program the sensor data to the LAUNCH-sensor and replace faulty sensor with low battery life or one that is not functioning. Select TPMS function Note: Do not place the device close to several sensors at the same time, or the diagnostic tool will detect more sensors, which may result in programming failure.
-
Page 9: Frequently Asked Questions
Frequently Asked Questions 1. How to save power? 5. My tool cannot trigger one or more of sensors. 1). Please turn off the screen while the tool keeps idle. Please check the following: 2). Set a shorter standby time. 1). Whether the device is damaged or defective. 3). - Page 10 Scan the following QR code to get the online Quick Start Guide of the corresponding language. LAUNCH...
-
Page 11: Fcc Warning
FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
