3. Product Descriptions

3.1 Outline of ROXIE W

No. Name
DB-15 diagnostic
1
connector
1
4
5
Figure 3-1
Descriptions
To connect to vehicle's DLC (Data Link Connector)
via diagnostic cable.
ROXIE W
2
3
User Manual
