4. Initial Use

4.1 Charging The Tool

There are two charging methods available:
Via Charging Cable: Plug one end of the included charging cable into the DC-IN
port of the tool, and the other end to the external DC power.
Via Diagnostic Cable: Insert one end of the diagnostic cable into the DB-15
connector of the tool, and the other end to the vehicle's DLC.
Once the charging LED illuminates solid green, it indicates that the battery is
fully charged.

4.2 Getting Started

If it is the first time you have used this tool, you need to complete the following
settings.
*Note: If you skip the initial sign-up and setup, alternatively you can configure it in the
"Settings" on the Job Menu.
1. Press the [POWER] button to power it on, the screen displays as follows:
10
?
ROXIE
Welcome to use
To begin using ROXIE, complete the following
steps.
Next
Figure 4-1
