3. Product Descriptions
3.1 Outline of Creader Professional 123X
1
No.
Name
1
Charging LED
2
LCD
3
5V Charging port
DB-15 diagnostic
4
connector
2
3
4
Figure 3-1
Descriptions
Red means Charging and Green means Fully
charged.
Indicates test results.
To connect to external DC power for charging the
tool.
To connect to vehicle's DLC (Data Link Connector)
via diagnostic cable.
Professional 123X User Manual
5
6
9
EN
7
8
7
