The pin out connections of the serial cable are as follows:
RJ45
1
2
3
4
5
6
7
8
The signal definition of the DB9F serial communication interface is as
follows:
Pin
RS232 signal
1
DCD
2
RXD
3
4
5
GND
6
DSR
7
8
Power
The input supply voltage range is 5~35VDC. We recommend using the
standard DC 12VDC/1.5A power adaptor available from Maxon.
Indicator Lights
The router has five indicator lights and operates as follows:
Indicator
Light
Power
System
DB9F
8
6
2
1
5
3
4
7
Direction
output
output
TXD
input
DTR
input
output
RTS
input
CTS
output
State
ON
OFF
BLINK
OFF
Status Description
Router is powered on
Router is powered off
System is up
System is down
Page - 15 -
