I n s t a l l a t i o n I n t r o d u c t i o n
Accessories List
Name
Router
Cellular Antenna
GPS Antenna
WIFI Antenna
Network cable
Serial cable
Power Lead
Stator
SIM card Installation
Power off the router, and press the eject button next to the SIM card tray
with a small sharp object. Upon doing so the SIM card tray will eject from
the face of the modem. Place the SIM card into the SIM card tray
(Ensure that the side of the SIM card with the metal connection points is
facing upwards), and then insert the SIM card tray back into the SIM
card outlet.
Antenna Installation
Attach the SMA male connector of the cellular antenna into the female
SMA interface on the router labeled "Antenna".
Attach the SMA male connector of the WIFI antenna into the female
SMA interface on the router labeled "WIFI".
The router supports an RS232 interface and a 10/100M Ethernet interface.
These two interfaces both utilize an RJ45 connector, with the RS232
interface labeled "Console" and the 10/100M Ethernet interface labeled
"ETH".
Plug the RJ45 end of the serial cable into the RJ45 outlet of the router
labeled "console", and plug the DB9F end of the serial cable into the
RS232 serial interface of the user's device.
Quantity
1
1
1
1
1
1
1
2
