S p e c i f i c a t i o n s

Cellular Specification

Standard and Band
MA100-1010 GPS+WCDMA ROUTER
UMTS/WCDMA/HSDPA/
HSUPA
850/1900/2100MHz,
850/900/1900/2100MHz
GSM850/900/1800/1900
MHz
GPRS/EDGE CLASS 12

WIFI Specifications

Standard IEEE802.11b/g
IEEE802.11n (optional)
Bandwidth IEEE802.11b/g: 54Mbps (max)
IEEE802.11n: 300Mbps (max)
Security WEP, WPA, WPA2, etc.
WPS (optional)
TX power 16-17dBm(11g), 18-20dBm(11b)
RX sensitivity <-72dBm@54Mpbs

Hardware System

CPU Industrial 32bit CPU
FLASH 4MB(Extendable to 16MB)
SDRAM 32MB(Extendable to 64MB)

Interface Type

Ethernet 1x 10/100 Mbps Ethernet port(RJ45), auto MDI/MDIX,
1.5KV magnetic isolation protection
LAN 4 10/100 Mbps Ethernet ports(RJ45), auto MDI/MDIX,
1.5KV magnetic isolation protection
Serial 1 RS232 port, 15KV ESD protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5, 2
Parity: none, even, odd, space, mark
Baud rate: 110~230400 bps
Indicator "Power", "System", "Online", "GPS", " Local Network ",
"WAN", "WLAN"
Bandwidth
HSUPA: 5.76Mbps
(Upload speed)
HSDPA: 7.2Mbps
(Download speed)
UMTS: 384Kbps
(DL/UL)
Page - 11 -
TX RX
power sensitivity
<24dBm <-109dBm
