Antenna Cellular: 2 x Standard SMA female interface, 50 ohm,
WIFI: Standard SMA female interface, 50 ohm,
SIM 2 x Standard 3V/1.8V user card interface with 15KV
ESD protection
Power Standard 3-PIN power jack, reverse-voltage and
overvoltage protection, 2.5mm barrel connector
Reset Restores the router to its original factory default
settings

Power Input

Standard Power
Voltage Range
Current
Consumption

Physical Characteristics

Housing
Dimensions
Weight

Environmental Limits

Operating Temperature
Extended Operating Temperature
Storage Temperature
Operating Humidity
DC 12V/1.5A
DC 5~35V
Minimum current: 450mA (12VDC)
Maximum Current: 600mA (12VDC)
* The product needs to be supplied by a limited
power source or the power supply provided.
Otherwise, safety will not be ensured
Metal
206x135x28 mm
805g
-25~+60ºC
-30~+75ºC
-40~+85ºC
95% (Non condensing)
