L2TP Client

Enable L2TP Client
L2TP Server IP (LNS)
Local Tunnel IP
User Name
Password

IPSEC Client

IPSEC Client settings must be configured to match your VPN Server setup.
Below is a sample configuration.
Enable or disable L2TP Client function
The L2TP server's IP Address
The local tunnel IP Address. "Auto" allocates the
local tunnel IP address from the PPTP Server
dynamically. You can also use the fixed local
tunnel IP if the PPTP Server supports it.
L2TP Server logon username
L2TP Server logon password
Page - 36 -
