Two 12 Pin Connectors - Danfoss JS1 series Electrical Installation

Electrical Installation
JS1 Heavy Duty Joysticks
Electrical installation
© Danfoss | December 2016

Two 12 pin connectors

Cabling and pin location: Two 12 pin DEUTSCH DTM04 connectors; Code number: 10102023-K (16 to 20 AWG)
Standard, 12 pin A pinout
Wire color
White
Brown
Yellow-Grey
Pink-Green
Grey
Violet
Grey-Pink
Red-Blue
White-Red
Brown-Red
Green
Whte-Yellow
Standard, 12 pin B pinout
Wire color
White
Brown
Yellow-Grey
Pink-Green
Grey
Violet
Grey-Pink
Red-Blue
White-Red
Brown-Red
Green
Whte-Yellow
12
1
12
1
kwa1454870808461
DEUTSCH DTM04 12 PIN
1
2
3
4
5
6
7
8
9
10
11
12
DEUTSCH DTM04 12 PIN
1
2
3
4
5
6
7
8
9
10
11
12
7
6
7
6
Function
Ground
Power
CAN high
CAN low
CAN shield
Proportional 1
Proportional 2
Proportional 3
Push 7
Push 8
PVE power (neutral switch)
PVE power feedback
Function
Direction 1a
Direction 1b
Direction 2a
Direction 2b
Direction 3a
Direction 3b
Proportional 4
Direction 4a
Direction 4b
Proportional 5
Direction 5a
Direction 5b
BC00000346en-US | 0201 | 9
