Electrical-Pve (Extended Only); Electrical-Can; Electrical Installation - Danfoss JS1 series Electrical Installation

Electrical Installation

JS1 Heavy Duty Joysticks
Product overview
Electrical—PVE (Extended only)
Electrical—CAN
6 | © Danfoss | December 2016
Electrical—PVE (Extended only) characteristics
Signal regulation U
s
Dead band compensation
Electrical—CAN characteristics
Sensor type
Resolution
Supply voltage (V )
s
Output
Base maximum current consumption
Base maximum survival supply voltage
U Minimum (50%)
s
U Maximum (200%)
+
U Minimum
s
U Maximum
+
Hall effect with redundant sensors
Potentiometer
12 bit
9 to 36 Vdc
J1939 and CANopen protocols
120 mA at 9V
68 Vdc
0.37 to 0.63
at 100% movement
0.25 to 0.75
at 50% movement
0.00
0.06
