Electrical Installation
JS1 Heavy Duty Joysticks

Product overview

Description

Electrical—PVE (Standard and Extended)
© Danfoss | December 2016
JS1 Heavy Duty Joysticks
The Danfoss platform offers a wide variety of new grip designs and were developed after extensive
research detailing operator needs. The JS1 heavy duty joysticks (JS1-H) and compatible grips meet the
demanding conditions typically found in mobile equipment environments. The available grips features
provide a high degree of protection from chemicals, shock, vibration and EMC exposure. Danfoss
joysticks are appropriate for both in-cabin and out of cabin applications and feature ergonomic forms
that minimize machine operator fatigue. The JS1-H ergonomic left-hand, right-hand and ambidextrous
(ST2) grip design options enable efficient operation and comfortable human-machine interface with easy
to use fingertip controls for maximum productivity. The grips feature a modular design that allows switch
and proportional rollers locations flexibility.
Electrical—PVE (Standard and Extended) characteristics
Supply voltages U
Current consumption
Sensor type
Signal voltage U Minimum to maximum
S
Neutral position
Signal load in neutral Load type
position
Load impedance
Signal current at U
maximum movement
U
Signal current in neutral U
position
U
Inverter Non inverted
Inverted
Maximum load for push buttons and directional switches for all proportional
functions
Neutral position switch
DC
= 12 V
DC
= 24 V
DC
= 12 V
DC
= 24 V
DC
9 to 36 Vdc
150 mA
Hall effect with redundant
sensors
Potentiometer
0.25 to 0.75
0.50
PVE Other
>6 kΩ >15 kΩ
6 kΩ 15 kΩ
± 0.6 mA 0.2 to 0.6 mA
± 1.2 mA 0.4 to 1.2 mA
± 0 mA ± 0.4 mA
± 0 mA ± 0.8 mA
Output signal = U
Output signal = -1 x (U
x U ) + 0.5x U
+
0.6 A
3 A
BC00000346en-US | 0201 | 5
s
-0.5
s
+
