Electrical Installation
JS1 Heavy Duty Joysticks
Electrical installation
10 | © Danfoss | December 2016

Two 12 pin and one 6 pin connectors

Cabling and pin location: Two 12 pin and one 6 pin DEUTSCH DTM04 connectors; Code number: 11176538-K
Extended, 12 pin A pinout
Wire color
White
Brown
Yellow-Grey
Pink-Green
Grey
Violet
Grey-Pink
Red-Blue
White-Red
Brown-Red
Green
Whte-Yellow
Extended, 12 pin B pinout
Wire color
White
Brown
Yellow-Grey
Pink-Green
Grey
Violet
Grey-Pink
Red-Blue
White-Red
Brown-Red
Green
Whte-Yellow
12
1
6
1
12
1
kwa1454871825360
DEUTSCH DTM04 12 PIN
1
2
3
4
5
6
7
8
9
10
11
12
DEUTSCH DTM04 12 PIN
1
2
3
4
5
6
7
8
9
10
11
12
7
6
4
3
7
6
Function
Ground
Power
CAN high
CAN low
CAN shield
Proportional 1
Proportional 2
Proportional 3
Push 7
Push 8
PVE power (neutral switch)
PVE power feedback
Function
Direction 1a
Direction 1b
Direction 2a
Direction 2b
Direction 3a
Direction 3b
Proportional 4
Direction 4a
Direction 4b
Proportional 5
Direction 5a
Direction 5b
