Electrical Installation
JS1 Heavy Duty Joysticks
Electrical installation
© Danfoss | December 2016
Extended, 6 pin pinout
Wire color
Yellow-Brown
White-Black
Brown-Black
Grey-Green
Yellow
NC

One 25 and One 6 D-Sub pin connectors

25 D-Sub pinout
Wire color
Green
Green
Brown
White-Blue
Red-Blue
White-Grey
Violet
Grey-Pink
Red
White-Yellow
Blue
Brown-Red
White-Red
Green
Brown
Yellow-Brown
White-Grey
White-Green
Grey-Brown
White-Pink
Pink-Brown
White
DEUTSCH DTM04 6-pin
1
2
3
4
5
6
1
14
25
13
6 4
3
1
wew1481755641811
25 pin D-Sub
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Function
Power
Push 9
Push 10
Push 11
Push 12
NC
Function
PVE power (neutral switch)
PVE power (neutral switch)
Power
Direction 5a
Proportional 3
Direction 3a/Push 1/*
Proportional 1
Proportional 2
Direction 2a (Y Dir A)
PVE Power feedback
Direction 1b (X Dir B)
Push 8
Push 7
PVE power (neutral switch)
Power
Power
Direction 5b
Proportional 4
Direction 3b/Push 2/*
Direction 4a/Push 3/*
Direction 4a/Push 4/*
Ground
