Electrical Installation
JS1 Heavy Duty Joysticks
Electrical installation

Connector options and cabling

© Danfoss | December 2016
Order separately from joystick.

One 6 pin connector

Cabling and pin location: One 6 pin DEUTSCH DTM04 connector
One 6 pin pinout
Wire color
White
Brown
Green
Yellow
Grey
NC

Two 6 pin connectors

Cabling and pin location: Two 6 pin DEUTSCH DTM04 connectors
Two 6 pin pinout
Wire color DEUTSCH DTM04 6 pin
White 1
Brown 2
Green 3
Yellow 4
Grey 5
NC 6
Pink
Blue
Red
Black
6 4
3
1
kwa1442328497987
DEUTSCH DTM04 6 pin
1
2
3
4
5
6
4
6
3
1
4
6
3
1
kwa1442328596963
DEUTSCH DTM04 6 pin
1
2
3
4
Function
Ground
Power
CAN high
CAN low
CAN shield
NC
Function
Ground
Power
CAN high
CAN low
CAN shield
NC
Ground
Power
CAN high
CAN low
BC00000346en-US | 0201 | 7
