Mating Connectors Bag Assemblies - Danfoss JS1 series Electrical Installation

Electrical Installation
JS1 Heavy Duty Joysticks
Electrical installation
12 | © Danfoss | December 2016
25 D-Sub pinout (continued)
Wire color
Black
Pink
NA
6 pin D-Sub pinout
Wire color
White
Brown
Yellow-grey
Pink-green
Grey
NC

Mating connectors bag assemblies

(must be ordered separately from joystick)
Danfoss connector bag assemblies part numbers
Description
One 6 pin DEUTSCH connector
Two 6 pin DEUTSCH connectors
One 12 pin DEUTSCH connector (GRY)
Two 12 pin DEUTSCH connectors (GRY/BLK)
Two 12 pin and One 6 pin DEUTSCH connectors (GRY/
BLK)
DEUTSCH mating connector bag assemblies contents
Description 6 pin module
Crimp tool HDT-48-00
Contacts 0462-201-2031
Connector plug DTM06-6S,GRY
Wedge WM-6S
Strip length 3.96 to 5.54 mm
(0.156 to 0.218 in)
Rear seal maximum 3.05 mm (0.120 in)
insulation OD
Sealing plugs 0413-204-2005
25 pin D-Sub
23
24
25
DEUTSCH DTM04 6-pin
1
2
3
4
5
6
Danfoss part number
10101551
11177980
10100944
10100945
11176538
12 pin module (GRY)
HDT-48-00
0462-201-2031
DTMO6-12SA, GRY
WM-12S
3.96 to 5.54 mm
(0.156 to 0.218 in)
3.05 mm (0.120 in)
0413-204-2005
Function
Direction 2b (Y Dir B)
Direction 1a (X Dir A)
NC
Function
Ground
Power
CAN high
CAN low
CAN shield
NC
12 pin module (BLK)
HDT-48-00
0462-201-2031
DTMO6-12SB, BLK
WM-12S
3.96 to 5.54 mm
(0.156 to 0.218 in)
3.05 mm (0.120 in)
0413-204-2005
BC00000346en-US | 0201
