Gait Sensor

The Gait Sensor consists of a pressure sensor and a transmitter. See Figure
5. The pressure sensor is used to detect when your foot is in the air and
on the ground. The transmitter is used to signal the L300 RF Stim Unit and
the Thigh RF Stim Unit to move your foot and knee accordingly. The Gait
Sensor communicates wirelessly with the L300 RF Stim Unit and the Thigh
RF Stim Unit.
Transmitter
Pressure
Sensor
Figure 5: NESS L300 Gait Sensor.
Chapter 5 - System Components and Accessories
Clamp
