Thigh FS Cuff

The Thigh FS Cuff is an ergonomic orthosis that fits over the hamstrings or
quadriceps muscles. The Thigh FS Cuff is designed to be used in unison
with the L300 FS Cuff, to assist with knee flexion or extension throughout
the gait cycle. See Figure 3.
The Thigh FS Cuff is available in right and left configurations, and houses an
integrated Thigh RF Stim Unit and two surface electrodes. The Thigh RF Stim
Unit produces the stimulation signal. The electrodes deliver the stimulation
signal from the Thigh RF Stim Unit to the hamstrings or quadriceps muscles.
Caution: The FS Cuffs should be removed from the skin every
three to four hours for 15 minutes to allow the skin to breathe.
Figure 3: The Thigh FS Cuff.
Chapter 5 - System Components and Accessories
RF Stim Unit
Cradle
Thigh FS
Cuff
Thigh RF Stim
Unit
