Jofemar Vision Snack Plus Technical Manual page 8

vision
Snack Plus/Easy Combo // Vending
Product selection pushbutton panel
The pushbutton panel consists of 16
keys divided into numerical
alphabetical (fig. 07). In addition to being
use to select a product, they are also
used in machine programming and the
configuration.
Lock
These machines feature a secure locking system consisting of a plate with three vandal-
proof anchoring points.
Programming pushbutton
It is located inside the door. This pushbutton is used to access all programming
functions: sale prices, messages shown by the display, resets, etc.
J-2000 compact (MDB/EXECUTIVE)
The machine can work with two different coin changers. The machine program changes
depending on the coin changer being used.
• J-2000 MDB coin changer without recovery motor (see the manual for the J-2000
MDB). The communication between machine and compact takes place using the
MDB protocol. The machine works as master while the compact works as slave.
When the machine is in service, the display shows the time and the temperature if the
type of sales programming is simple or mixed single 2 (
mode only the coins or banknotes whose value can be returned will be accepted and the
maximum credit that we can enter can never exceed the maximum recovery (
16). Furthermore the maximum recovery is updated automatically with the higher price in
the case where such price exceeds the value of the maximum recovery.
In mixed single sales mode 2, when accepting coins or banknotes no whether they can
be returned or not is not taken into account.
In the two types of sales the credit that can be accepted is limited by the higher price
programmed. Therefore to ensure the proper operation of the machine check that the
maximum recovery and the prices are properly programmed (
address 00 respectively). In single sale mode you need to insert money until you reach
or exceed the price of the desired product. When you use they key pad to enter the
product selection, the display shows the price of the product. If such price is less than or
equal to the money inserted, the product is not out of stock and there is enough change,
se concede the sale.
MNP86V03GBV00
and
Date: 2010/06/14 Rev. 0
Fig. 07
address 15). In single sales
address
address 16 and
PAGE 8 OF 62
