Installation and
Maintenance Guide
Contents
Machine Layout
Characteristics
Installation
Programming mode
Programming options
First load of the coin changer
Reloading of the products
Fault checking and resetting
Preventive maintenance and cleaning
Adjusting channels to new products
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN
:
Read the safety instructions at page 19 of this manual be-
fore starting working on the machine.
Easy Plus
Easy Plus
Tel. +34 948 75 12 12
Fax +34 948 75 04 20
www.Jofemar.com
www.Jofemar.com
www.Jofemar.com
www.Jofemar.com
Page 1 of 20
Advertisement
Related Manuals for Jofemar vision easy combo
Summary of Contents for Jofemar vision easy combo
- Page 1 Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN www.Jofemar.com www.Jofemar.com www.Jofemar.com www.Jofemar.com Page 1 of 20...
- Page 2 Layout of the machine: Exterior of the machine 1.- Display glass (Or front picture on EasyPlus model) 2.- Card reader entry 3.- Display 4.- Bill validator entry 5.- Refund button 6.- Coin entry 7.- Door lock 8.- Selection buttons 9.- Coin return cup 10.- Delivery door 11.- Ventilation grille Interior of the machine- cabinet...
- Page 3 Combo and to it’s right a Vision If you need more capacity or diversity on E - S, optional satellite unit to your sales point chech with you Jofemar the main Vision agent about the possibilitie of an Extra machine. Selections Unit...
- Page 4 Installation Installation of the machine: To remove the trans- 1.- Level the machine, the machine port paws Jofemar transport paws can be replaced by optionally provide the adjustable paws by which the with a jack specially machine can be properly levelled.
- Page 5 Programming mode: Elements of the programming system: Detail of the programming button on the 1.- Programming button interior of the door Press this button to get into the programming mode. It’s recommended to close the door once it’s on the programming mode in order to avoid any loss of temperature inside of the machine.
- Page 6 Programming map: Programming Options: In order to put into service: Communication via modem (MDB) Prices programming Fourth step Product accountings Reloading of change tubes (MDB) Fifth step Unloading of change tubes (MDB) Money accountings (MDB) Second Step Setting of the clock Fault checking Clearing all faults Third step...
- Page 7 Language selection: Scroll through the programming options until you reach option “32” “Language Programming” Press to visualize the program language Press to change to the desired language Set the clock: Scroll through the programming options until you reach option “05” “Setting of the clock”...
- Page 8 Assigning the channels to the selection numbers: (Only change the confi guration if necessary) Scroll through the programming options until you reach option “09” “Machine Composition” and press At that moment, the machine will ask you for a selection number. Once you enter the selection number for that product, the machine will ask you for the channel number for that product.
- Page 9 Pricing the selections: Scroll through the programming options until you reach programming option “00” “Prices Programming” and press The display will read price $ 0.00 Depending on the machine program we can fi nd two diff erent modes to program the price: Mode A: Button...
- Page 10 Load of the coin changer: First load of the coin changer J-2000: If the tubes of the coin changer are totally empty, do the fi rst initial load: Press once button 1 of the coin changer to get to option 25 and insert coins in this order(*) Three coins for tube 2 Three coins for tube 3...
- Page 11 Checking and resetting faults: Functioning of the coin changer programming: Button 1: To go into programming mode and scrow through the options 1.- ACCESS 2.- TO CHECK THE TO THE OPTION Button 2: PROGRAMMING OPTIONS To get into a specifi c option and go through its different fi elds.
- Page 12 Review and resetting faults of the machine: In case a malfunction has been detected follow the next steps: Go through the programming options until you reach option “06” “Fault Checking” Press button to display all the general faults of the machine Press button to display all the tray photosensors short-circuited...
- Page 13 Maintenance and cleaning: Clean the interior and exterior of the glass with a damp cloth by The glass or pidcture front should to be using a suitable glass cleaning cleaned periodically with a cloth or a product damp sponge Keep the air entrance free The ventilation grille on the bottom of the from dirt and objects from the machine...
- Page 14 Product delivery system: Each of the machine channels has a back pusher to move the whole line of products. We will diff erentiate between two channel models: recommended for uniform shape products recommended for uniform shape products recommended for uniform shape products recommended for uniform shape products recommended for uniform shape products recommended for uniform shape products...
- Page 15 General reloading of the products: 1.- When you stock products in the When you stock products in the machine put the “new” products machine put the “new” behind the remaining product by products behind the placing the pusher to the back of the remaining product by channel.
- Page 16 General reloading of the products: products in vertical 7.1.- Place products standing up with the position brand facing the customers. 7.2.- Products pushers come with a In order to adjust the pusher to the width of the channel, precut break off point that allow you break off the excess by to adjust the width per any channel pulling forward...
- Page 17 Setting the voltage of the motors Scroll through the programming options until you reach option “25” “Voltage for channel motors” and press A message saying “Voltage programming” will appear, press The display will read 5.0 volts. To change this voltage: Button increases in 0.5 volts increments...
- Page 18 Adjusting channels to new products: On case we want to change the product a motor is selling and the new product is thicker or thinner than the current one Empty the channel follow the next steps: of the products we want to replace 1.- Empty the channel with the old product.
- Page 19 ◊ If you need to replace the power supply cable, please replace it with the appropriate one for your country: Argentina, Jofemar code 5500014. Australia, Jofemar code 5500006. Spain (STANDARD), Jofemar code 5500000. UK, Jofemar code 5500011. Switzerland, Jofemar code 5500004. USA, Jofemar code 5500010.
- Page 20 Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN Ctra, Marcilla, Km.2. 31350 PERALTA, Navarra SPAIN www.Jofemar.com www.Jofemar.com www.Jofemar.com www.Jofemar.com Page 20 of 20...
