vision
Snack Plus/Easy Combo // Vending
• Temperature on display: it is possible to display the machine internal temperature
at the same time that the time is shown on the display.
TEMPERATURE
ON DISPLAY
• Cut-off temperature: you can program the cooling unit cut-off temperature with
values between 4 °C and 12 °C.
WORKING
TEMPERATURE
Value
+04.5ºC
The value is increased or decreased in steps of 0.5 °C.
• Expiry temperature: this is the temperature from which the ATMEGA begins to
count the time to consider the product as expired.
EXPIRATION
TEMPERATURE
Value
00.0ºC
The value is increased or decreased in steps of 0.5 °C.
SAVED
VALUE
If the new value has been properly recorded the display will show a message saying so.
• Expiry period: is the period that the product hold has to be at a temperature equal
or greater than the expiry temperature to consider that the product has expired.
When you access this option, the value (hours) currently programmed in the
ATMEGA is displayed.
EXPIRATION
PERIOD
Period (hours)
04
Period (hours)
SAVED
TEMPERATURE
OPTIONS
[19] DATE EXPIRY OPTIONS
At this address you can program individual expiry dates both for products and for
channels.
• Programming the expiry date for each product:
Enter the product selection menu (day – month). Once you have entered the date
correctly, you will access the menu to choose the selection number where you can
select all the selection numbers to be programmed with the date you have previously
MNP86V03GBV00
Display the
temperature
Value
+04.0ºC
Value
+04.0ºC
Value
-00.5ºC
Value
+00.5ºC
Records the new
microprocessor
Period (hours)
03
Period (hours)
05
Records the new
microprocessor
To return from the menu of any of the options to the
main menu of the address.
EXPIRATION
OPTIONS
Date: 2010/06/14 Rev. 0
Do not display
temperature
Value
00.0ºC
value in the ATMEGA
Period (hours)
04
value in the ATMEGA
