[40] PROGRAMMING THE CALLING SCHEDULE (MDB)
This address will appear if the machine has been connected to a modem interface card.
There are 3 options:
• Calling time: The time when the machine should call the management centre each
day. There is a two hour margin to make the call at 1-minute intervals between tries.
• Begin standby time: Time from which the machine will be waiting for a call from the
management centre.
• End standby time: Time at which the machine will cease to wait for a call from the
management centre.
The setting that you can change will blink on the display.
1 2 3+ 4- c-del
99:99
To toggle between settings, that is, from hours to minutes and vice versa
1 2 3+ 4- c-del
99:99
To increase it or decrease it.
1 2 3+ 4- c-del
01:99
1 2 3+ 4- c-del
99:99
[41] PROGRAMMING THE TELEPHONE NUMBER (MDB)
This address will appear if the machine has been connected to a modem interface card.
When you access this address you will see the number currently programmed. The
cursor will blink to show its position.
1 2 3+ 4- c-del
#
To move the cursor toward the right or toward the left.
1 2 3+ 4- c-del
#
When you reach the last character (#)will be displayed to indicate that you cannot
continue. If an arrow ( )is visible you can continue advancing. The telephone
number can have a maximum of 20 characters. Once the cursor is in place, you can
MNP86V03GBV00
1 2 3+ 4- c-del
99:99
1 2 3+ 4- c-del
99:01
The value of the hours and the minutes will be
set at 99, equivalent to a null value that will
disable this option.
1 2 3+ 4- c-del
#
Date: 2010/06/14 Rev. 0
PHONE TIMES
PROGRAMMING
PHONE NUMBER
PROGRAMMING
