7 Technical Data
Flow rate*
(measuring point at suction
tube nozzle)
Vacuum
Canister
Suction tube
Nominal voltage of the
power supply unit
Maximum load current
Permissible input voltage
Power consumption at 12 V
Degree of protection pursu-
ant to IEC 60601-1
Risk classification pursuant
to 93/42/EEC, IX
Protection class pursuant to
IEC 60601-1
IP degree of protection
CE marking
Sound emission
26
ASSKEA M20 : 22 l/min ± 2 l/min (high flow)
Plus
ASSKEA M30 Plus : 30 l/min ± 2 l/min (high flow)
(free flow – lower in curbed operation)
max. -90 kPa (~ -900 mbar; -675 mmHg) (high vacuum)
Conversion factor: 1 kPa ~ 7.5 mmHg
Reusable secretion canister system (1000 ml);
Disposable secretion canister system (1000 ml)
PVC, inner diameter 6 mm, wall thickness 2 mm,
length 150 cm, vacuum stable up to -0.9 bar
In: AC 100-240 V ~ 50-60 Hz / 1.5 A
Out: DC 12 V / 5 A
5.0 A
12 V
60 W
Type BF
IIa
II
IP22
CE0843
without vacuum: approx. 66 dB(A)
