MODEL NO. DXV35 TIMBERFIRE DIRECT VENT GAS FIREPLACE HEATER
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result causing property damage, personal injury or
loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gasses, unless a
certified kit is used.
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and must be installed.
Installation and Operating Instructions
85-03-01115-E
AVERTISSEMENT. Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d'incendie ou d'explosion ou pour
éviter tout dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres vapeurs
ou liquids inflammables dans le voisinage de cet appareil
ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incendies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
Cet appareil peut être installé dans une maison
préfabriquée (É.-U. seulement) ou mobile déjà installée à
demeure si les règlements locaux le permettent.
Cet appareil doit être utilisé uniquement avec les types de
gaz indiqués sur la plaque signalétique. Une trousse de
conversion est fournie avec cet appareil.
Une barrière conçue pour réduire le risque de brûlures
du verre chaud est fournie avec cet appareil et doit être
installée.
DXV35 TIMBERFIRE

Advertisement

Table of Contents
loading

Related Manuals for Mendota DXV35 TIMBERFIRE

Summary of Contents for Mendota DXV35 TIMBERFIRE

  • Page 1 Installation and Operating Instructions MODEL NO. DXV35 TIMBERFIRE DIRECT VENT GAS FIREPLACE HEATER WARNING: If the information in these instructions AVERTISSEMENT. Assurez-vous de bien suivre les is not followed exactly, a fire or explosion may instructions données dans cette notice pour réduire au...

  • Page 2: Hot Surfaces Are Normal

    See chapter Instructions. Read and 3.1.1 Mendota Fireplace Curing follow all instructions given in this Chapter and perform the 3-step curing cycle. After the 3-step curing cycle has been completed, all smoking will have stopped. Some slight odors may remain. With subsequent use of this Fireplace, odors will slowly dissipate and disappear.

  • Page 3: Table Of Contents

    Table of Contents 3.2.7.3.1 Mendota Cool Wall ........... 31 .. 2 CAUTION STATEMENTS TO PARENTS OF YOUNG CHILDREN 3.2.7.3.2 Versiheat ..........32 1.2 I ....... 2 3.2.7.3.3 FlexHeat ........... 33 NITIAL IRING AND URING ROCEDURE 1.3 H ........2 URFACES ARE ORMAL 1.4 P...
  • Page 4 6.1 R ....... 74 EQUIRED ERIODIC NSPECTIONS 6.2 C ......... 74 LEANING IEWING LASS 6.3 R ......75 EQUIRED NNUAL AINTENANCE 6.4 O ....76 IRING OR NDER IRING OF URNER ........ 76 PILOT OUTAGE AND IGHTING 6.6 B .... 76 URNER LAME EIGHTS...

  • Page 5: Safety And Warning Information

    Building Permit & Inspection Requirements All installations of Mendota Fireplaces must comply with all the requirements stated in this Installation and Operating Manual. The dealer and/or installer must obtain all required building permits and inspection approvals from the local building inspection department or the local jurisdiction.

  • Page 6: Safety Warnings

    HIGH-ALTITUDE INSTALLATION INFORMATION: Prior to installing at altitudes higher than 7,500 ft., understand the need for gas input derating. Contact your local gas company to see if your gas type is already derated for your altitude or contact Mendota Technical Service for support.
  • Page 7 Never obstruct the flow of combustion and ventilation air. Keep the front of the fireplace clear of all obstacles and materials for servicing and proper operation. Use only Mendota approved Screens, Fronts and Trim Kits. Due to high temperature, the firepl ace should be located out of traffic areas and away from furniture and draperies.
  • Page 8 été plongée dans l’eau. Do not use any fronts or doors with this fireplace unless they are certified by Mendota and installed by a certified installer.
  • Page 9 A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation 85-03-01115 DXV35 TIMBERFIRE Page 9...

  • Page 10: General Technical References

    If pilot goes out, always wait 5 minutes before attempting to relight pilot. Never block off convection air openings or paths. Trim panels or surrounds shall not seal ventilation openings in the fireplace. Always use Mendota decorative fronts and Mendota approved vent systems and vent caps only. Keep the flue warm It is required to leave the pilot light running during winter months when outside daily high temperatures remain 50 F or lower.
  • Page 11 ATTENTION It is important that the blowers are turned on during this step to prevent the curing smoke from staining the wall finish above the fireplace. Mendota recommends completing Step 1 prior to install ation of wall finish materials. Visible smoke and strong odor are to be expected during this step. If desired, disable smoke alarms before this step, smoke from the initial curing c ycle will set off smoke alarms.

  • Page 12: Mechanical Technicalr

    The listing label is in the air gap beneath the firebox behind the lower grill of the Fireplace. It is secured to a chain and can be pulled out to be viewed. Figure 3-1 Listing Label 85-03-01115 DXV35 TIMBERFIRE Page 12...
  • Page 13 A few warnings or caution labels are attached to this appliance body as required per code to inform you of important facts. Make certain you heed all the warning and caution statements during installation and maintenance of this appliance. Figure 3-3 Figure 3-2 Figure 3-5 Figure 3-4 Figure 3-7 Figure 3-6 Figure 3-8 85-03-01115 DXV35 TIMBERFIRE Page 13...
  • Page 14 Figure 3-9 Figure 3-10 85-03-01115 DXV35 TIMBERFIRE Page 14...
  • Page 15 Planning the installation This Mendota Fireplace must be installed and serviced by a qualified installer, service agency, or the gas supplier. When planning on appliance installation, it is necessary to determine the following information before installing: • Where the appliance is to be installed.
  • Page 16 Dimensions and Technical Details DXV35 TIMBERFIRE Fireplace Ratings Information This Mendota Fireplace can be installed directly on top of a metal, masonry or wood structural surface. ELECTRICAL REQUIREMENTS: 120 Volts AC, 1.5 Amps (minimum line voltage allowed 110 Volts AC) REQUIRED GAS SUPPLY PRESSURE: NAT.
  • Page 17 LPG INFORMATION: LP conversion kit #HA-30-00237 is required. 12”WC Minimum inlet pressure required. For the DXV35 Timberfire LPG application, the orifice is to be drill size #50. For higher altitude, adjustment to orifice size may be necessary. 85-03-01115 DXV35 TIMBERFIRE Page 17...
  • Page 18 Note: For every 1” this fireplace is raised off the floor, the non-combustible hearth protection pad may be reduced by 2”. If this fireplace is raised more than 6” off the floor, no hearth protection pad is required. See Chapter 3.2.4.2 Hearth Pad Requirement Chapter 3.2.5.1 Hearth Pad Temperatures 85-03-01115 DXV35 TIMBERFIRE Page 18...
  • Page 19 If the mantel is constructed of non combustible materials, it may be placed at any distance above the top air gap. Caution: Materials made of porous stones or sedimentary rocks may crack due to expansion of the material if placed around this appliance. Use suitable materials which are crack resistant and high temperature resistant. 85-03-01115 DXV35 TIMBERFIRE Page 19...
  • Page 20 If the appliance is being installed on a cement slab, a layer of plywood may be placed underneath this fireplace to prevent conducting cold up into the room Figure 3-19 Floor to Vent Cap Center Dimension 85-03-01115 DXV35 TIMBERFIRE Page 20...
  • Page 21 3. Minimum Clearance from vertical vent pipe sides to combustibles is 1”. 4. Minimum Clearance below horizontal vent pipe or components is 1”. 5. Minimum Clearance above elbows and horizontal vent pipe and components is 2”. 85-03-01115 DXV35 TIMBERFIRE Page 21...
  • Page 22 This fireplace may be installed in an elevated position by created an elevated deck and an appropriate framed enclosure. NOTE: This fireplace may be elevated but MUST allow a minimum of 72” distance between this fireplace’s floor level and the ceiling of the room. Figure 3-22 HEARTH PROTECTON PAD 85-03-01115 DXV35 TIMBERFIRE Page 22...
  • Page 23 Doing so can lead to a severe fire hazard. Note: The distance from the Floor Level of this Fireplace to the Top Air Gap is 27”. Figure 3-23 Mantel Clearances Figure 3-24 Mantel Clearances 85-03-01115 DXV35 TIMBERFIRE Page 23...

  • Page 24: Horizontal Clearance Reduction By 66

    NPFA 211 Approved: Install an R-1 rated ceramic board or R-1 rated mineral board on the wall you are attempting to protect. by using this method of protection, if the required horizontal clearance was 12”, the resulting clearance will be reduced by 50% to 6” between the heat source and the R-1 Rated wall board. 85-03-01115 DXV35 TIMBERFIRE Page 24...
  • Page 25 Suitable Mantel, Facing & Hearth Pad Materials Use of ceramic glazed tiles as facing materials around a Mendota Fireplace is approved. Use caution when selecting tile adhesives. Avoid premixed tile adhesives which contain products that can off gas for long periods when exposed to heat. Use Portland cement based unmixed tile adhesives or RTV Silicone to attach ceramic glazed tiles as facing in hot areas around this Fireplace.
  • Page 26 Mendota Fireplaces. Mendota further cautions that proper adhesives be used to attach stone facings. Pay attention to the potential of off-gassing of chemical vapors from mastic and other adhesives. Improper selection can lead to emission of chemicals with unwanted smells.
  • Page 27 R-Values of Common Facing Materials Material Thickness R-Value Cement Mortar 1/2" 0.100 Concrete 1" 0.095 Ceramic Tile 1/4" 0.020 Flagstone 1" 0.079 Granite 1" 0.083 Limestone 1" 0.153 Marble 1" 0.090 Sandstone 1" 0.079 Slate 1" 0.100 85-03-01115 DXV35 TIMBERFIRE Page 27...

  • Page 28: Paint Types Approved For Use

    Moisture content of the wood substrate is also of critical importance. High moisture content wood when heated will yield evaporation of the moisture and hydraulic pressure under the paint or sealants which can lead to peeling or bubbling. Always select the lowest moisture content wood substrate. 85-03-01115 DXV35 TIMBERFIRE Page 28...
  • Page 29 Many television manufacturers specify in their installation instructions that the television must not be installed near or above a heat source. The decision to install a television near or above a Mendota fireplace rests solely on the consumer. It is the consumers responsibility to satisfy television specifications and insure the television will not exceed maximum operation temperatures.
  • Page 30 Recommendation 3: Install a heat transfer system Mendota Hearth offers three heat transfer systems that take heat from the fireplace and redirect it to another area. When used correctly these heat transfer systems can make it possible to mount a television above the fireplace without installing a mantel or creating a recessed cavity.

  • Page 31: Mendota Cool Wall

    Mendota Cool Wall The Mendota Cool Wall system uses natural convection to take heat off the wall directly above the fireplace and redirects it up and away from surrounding areas. Testing has shown that when using a Cool Wall system, temperatures above the fireplace are reduced making it possible to mount a television 15”...

  • Page 32: Versiheat

    Because the Versiheat system must be running to reduce temperatures the fireplace cannot be operated during a power outage. Testing has shown that when using two Versiheat systems temperatures above the fireplace are reduced making it possible to mount a television 15” above the fireplace’s top air gap. 85-03-01115 DXV35 TIMBERFIRE Page 32...

  • Page 33: Flexheat

    Because the FLexHeat system must be running to reduce temperatures the fireplace cannot be operated during a power outage. Testing has shown that when using the FlexHeat system temperatures above the fireplace are reduced making it possible to mount a television 12” above the fireplace’s top air gap. 85-03-01115 DXV35 TIMBERFIRE Page 33...
  • Page 34 Stove gasket cements may be used at pipe joints but is not required The DXV35 TIMBERFIRE Fireplaces requires coaxial rigid- 4” diameter exhaust & 6-5/8” diameter air inlet and approved vent caps for most installations. In some special cases, flexible ducting may be used. Contact Mendota Technical Service Department if your installation requires other than standard rigid 4”...
  • Page 35 Flue Venting Components Identification Diagrams Prior to installing at altitudes higher than 7500, please contact the Mendota technical service department for specific venting requirements and venting restrictions. ITEM DESCRIPTION 6" or 7” PIPE (DuraVent 6”/Amerivent 7”), 9”, 12” 12" VENT STACK 24"...

  • Page 36: Figure

    Approved Vent Systems Figure 3-29 Approved Vent Systems 85-03-01115 DXV35 TIMBERFIRE Page 36...
  • Page 37 (45 cm) minimum ) Clearance to inside corner - 12 inches (30 cm). Minimum 24” horizontal clearance to any surface, Vinyl surfaces require 24” min (60 cm). such as an exterior surface, for vertical terminations. 85-03-01115 DXV35 TIMBERFIRE Page 37...

  • Page 38: Figure

    Alternatively, you may also vertically extend the wood burning flue liner up 24” higher than the top surface of the gas appliance vent cap. Figure 3-30 Side by Side Vent Caps 85-03-01115 DXV35 TIMBERFIRE Page 38...

  • Page 39: Figure

    Decorative Cover for Vent Cap It is acceptable to install a decorative stone, metal or terra cotta cover to disguise the vent terminal/cap used on Mendota Fireplaces if the decorative cover meets the following minimum requirements: The decorative cover shall be manufactured from noncombustible materials.

  • Page 40: Lectrical Technical References

    ¾”. Twist the braided wire around the solid copper wire end before applying the wire nut. 3. Place connected wire ends within junction box then close and secure the junction box cover plate. AC Power Connection STEP 1 STEP 2 STEP 3 Figure 3-33 Wire Connections 85-03-01115 DXV35 TIMBERFIRE Page 40...
  • Page 41 Replacement wires must have the same type and size of Code. insulation as the original. Label all wires prior to disconnection when servicing control. Wiring Errors can cause improper and dangerous operation. Verify proper operation after servicing. 85-03-01115 DXV35 TIMBERFIRE Page 41...

  • Page 42: Lumbing Technical References

    TRAIN. ADHERE STRICTLY TO LOCAL AND NATIONAL CODES. Gas Supply Line Sizing This Mendota Gas Fireplace comes equipped with a 1/2" N.P.T. Female inlet. Gas supply piping must enter the Fireplace cabinet on the left side. Use the table, below, to determine the proper gas line diameter that must be installed to run from the supply regulator to the inlet end of the main gas valve.
  • Page 43 Local requirements supersede all other codes. Figure 3-38 Keyed Manual Gas Shutoff Valve 85-03-01115 DXV35 TIMBERFIRE Page 43...
  • Page 44 The gas inlet fitting supplied with this Fireplace provides a 3/8” female NPT fitting. This requires you to supply a 3/8” NPT male fitting for connection to this appliance. Based on the gas line size you have selected use an appropriate NPT fitting to adapt and connect to the 3/8” male NPT flex end adapter. 85-03-01115 DXV35 TIMBERFIRE Page 44...
  • Page 45 This appliance has been converted for use at an altitude of: Orifice size: Manifold Pressure: Input (Btu/h): Fuel Type: Date of conversion: Converted by: Cet appreeil a été converti au ____ Injecteur ________ Pression à la tubulure d'alimentation _____________ Déoit calorifique ______________ 85-03-01115 DXV35 TIMBERFIRE Page 45...

  • Page 46: Installation Checklist

    ❑ Adjust vent damper to match vertical chimney length. See 4.4.1 Vent Damper Adjustments ❑ Co-axial vent rigid pipe, wall vent cap or roof vent cap is installed by a Mendota approved serviceperson in accordance with instructions. ❑ All joints are secured, "twist-locked" and leak-proof.

  • Page 47: Preparing For Installation

    Lift the outer box vertically straight upward until lower edge of the box clears the top of the unit body. Set the box aside. Mendota recommends recycling the outer box. Figure 4-1 Outer Box Removal 85-03-01115...
  • Page 48 Contents of the Manual Packet Once the outer box is removed, you will find the Fireplace body and a manual packet. This manual packet includes the items shown in the table, below. Contact Mendota Technical Service if any parts are missing. Owner’s Manual.
  • Page 49 3. Remove screw driver. Insert screw driver tip into one hole in clip. Lift screw driver up. To break clip off, repeat up down motion of screw driver seven to eight times. Figure 4-4 Shipping Clip STEP 1 & STEP 2 STEP 3 Figure 4-6 Bend Up Clip 2 Figure 4-5 Bend Up Clip 1 85-03-01115 DXV35 TIMBERFIRE Page 49...
  • Page 50 Pull Holding Bar down and outward (away from Fireplace) until it clears doorframe. Raise Bar until it fits securely in Bar Holding Brackets on doorframe. Repeat procedure for opposite Holding Bar. Door is now connected and sealed to unit. 85-03-01115 DXV35 TIMBERFIRE Page 50...

  • Page 51: Natural Gas To Lpg Conversion

    WRENCH TO tool to hold, LOOSEN HOOD loosen and tighten PILOT ORIFICE pilot hood base to prevent damage to pilot mount bracket. Figure 4-8 VALVE ASSEMBLY Figure 4-9 Pilot Orifice Access 85-03-01115 DXV35 TIMBERFIRE Page 51...
  • Page 52 LP Pressure Regulator can only be mounted in one GAS VALVE BODY position. Secure the LP Pressure Regulator in place using the 3 screws you removed in Step 2. Tighten NG PRESSURE down using a ¼” flat blade screwdriver. REGULATOR 85-03-01115 DXV35 TIMBERFIRE Page 52...
  • Page 53 The pilot light flames must be a minimum of 1” long and must overlap the propagation ports on both the rear and front burner legs. Verify that the burner tubes ignite quickly and the burner flames propagate smoothly along the entire length of the burner. 85-03-01115 DXV35 TIMBERFIRE Page 53...

  • Page 54: Enting

    Fireplace. Oversights or failure to conform to all installation requirements will void the applicable warranty. The DXV35 TIMBERFIRE Fireplace must be vented vertically to the outside and must use a rigid coaxial ducting system. This heater must be properly connected to a venting system in accordance with the manufacturer's installation instructions.
  • Page 55 DXV35 TIMBERFIRE Master Venting Chart Note: This chart is applicable to both natural gas and LP installations. ❑ 12” minimum vertical pipe run required to be connected directly to this fireplace’s flue starter collar. ❑ Maximum horizontal run allowed with the minimum 12”...
  • Page 56 Using 90 Elbows The DXV35 TIMBERFIRE Fireplace by MENDOTA allows maximum flexibility in the use of 90 elbows in the vent system. The length of the first straight vertical section directly connected to the fireplace’s starter collar determines the maximum horizontal run and the number of 90 elbows allowed for this fireplace.
  • Page 57 Seal with high-quality caulking around the outer perimeter of the vent cap. Note: Vent cap shall not be recessed into wall or siding. Figure 4-12 MINIMUM RISE HORIZONTAL VENT 85-03-01115 DXV35 TIMBERFIRE Page 57...
  • Page 58 Be sure to maintain 1" air space to any combustibles on the sides and bottom, 2" above horizontal pipe sections. THIS FIREPLACE MUST BE INSTALLED BY A QUALIFIED MENDOTA APPROVED SERVICEPERSON. Position fireplace in desired location. Check to determine if wall studs are in the way when vent system is attached. If this is the case you may want to adjust the fireplace location.
  • Page 59 2” above horizontal pipe sections and components. THIS FIREPLACE MUST BE INSTALLED B Y A QUALIFIED MENDOTA APPROVED SERVICEPERSON. Place the fireplace in its desired location. Drop a plum bob from the ceiling to the position of the fireplace flue exit.
  • Page 60 Damper Position Indicator. Loosen damper base screw. Turn counter-clockwise to close the vent damper, tighten screw. If this fireplace’s vent is terminated horizontally, DO NOT CLOSE the vent damper completely. Figure 4-13 Exhaust Damper Adjustment 85-03-01115 DXV35 TIMBERFIRE Page 60...

  • Page 61: Timberfire Log Set Installation

    5. Reinstall door, and check for smooth ignition again. If any delay occurs, make sure that no coals or wool is blocking pilot from front or rear burner holes. Remove glass door, correct problem and repeat steps 4 and 5. 85-03-01115 DXV35 TIMBERFIRE Page 61...
  • Page 62 85-03-01115 DXV35 TIMBERFIRE Page 62...
  • Page 63 85-03-01115 DXV35 TIMBERFIRE Page 63...
  • Page 64 85-03-01115 DXV35 TIMBERFIRE Page 64...
  • Page 65 Note: Installer, save and give the copy of the Log Set Installation Instructions to the homeowner for future references. 85-03-01115 DXV35 TIMBERFIRE Page 65...

  • Page 66: Air Shutter Control And Flame Appearance

    IMPORTANT: Try each new shutter setting approx. ½ hr. before making additional change s. NOTE: Changes in front burner flame can be made by re -arranging the coals and front burner air shutter opening. 85-03-01115 DXV35 TIMBERFIRE Page 66...

  • Page 67: Lighting Checklist

    ☐ DO NOT proceed with operation unless burner cycles "on/off" without delays and the flame is "stable" and not "lifting" off burner after 5 minutes of initial ignition. Caution: If pilot goes out, be sure to wait a minimum of five minutes before relighting. 85-03-01115 DXV35 TIMBERFIRE Page 67...

  • Page 68: Aesthetic Considerations

    We are committed to quality and satisfaction for all Mendota owners. Thank you for choosing a Mendota to be a source of comfort and beauty in your home.

  • Page 69: First Time Lighting Instructions

    Logs or coals must not block pilot flame or main burner flame. Vent system must be leak proof. DO NOT PROCEED WITH OPERATION UNLESS BURNER "CYCLES" ON/OFF WITHOUT DELAYS! 85-03-01115 DXV35 TIMBERFIRE Page 69...

  • Page 70: T Oturn Off Gas To Fireplace

    Turn Thermostat to "OFF". Pilot will remain lit for return to normal service. 2. For complete shutdown turn Gas Cock Dial to "OFF". Turn off the internal manual shutoff valve in the appliance. See 3.4.6 Factory Installed Manual Gas Shutoff Valve. 85-03-01115 DXV35 TIMBERFIRE Page 70...

  • Page 71: Frequently Asked Questions

    Where can I find the model and serial numbers? When requesting service, you will be asked to provide the model number and serial number to your Mendota dealer. This information will expedite the warranty verification process. The Listing Label contains the model number and serial number for your particular appliance.

  • Page 72: What Maintenance Is Required

    3” to 12” long area) and the gasket adhesive in no longer functional to stick to glass, then replace the gasket. Visually inspect the vent terminal (vent cap) for leaves, twigs and other debris accumulation. Clean if required. 10. Clean door glass. 11. Clean enamel firebox lining, if one is installed. 85-03-01115 DXV35 TIMBERFIRE Page 72...
  • Page 73 These adjustments should be made by a qualified technician to achieve the best flame performance. Contact your installer or Mendota dealer if you feel your fireplace is not burning correctly. Improper setup and adjustment is not covered under warranty.

  • Page 74: Equired Eriodic Nspections

    WARNING: Do not clean when glass is hot. The viewing glass should be cleaned periodically. Exterior glass surface may be cleaned with cleaner as desired. To Figure 6-1 Pilot Flame Lengths clean Interior glass surface, remove glass frame assembly. See 0 85-03-01115 DXV35 TIMBERFIRE Page 74...

  • Page 75: Equired Nnual Aintenance

    Check joints between the gasket pieces at the corners. They should butt against each other to create a seal. Gaps between gasket pieces can cause exhaust leaks and lead to acrid smell concerns. 85-03-01115 DXV35 TIMBERFIRE Page 75...

  • Page 76: Ver Firing Or Under Firing Of Burner

    If you are using a “backyard” Natural Gas well as the gas source, you must submit formal gas analysis data sheets to Mendota Fireplaces for review and calculation of proper main burner orifice sizes prior to first firing. It is known that unpurified Natural Gas from “backyard” wells can contain high energy levels causing over firing.

  • Page 77: Replacement Parts Information

    R H BLOWER WITH MOTOR 35-01-00601 FIREBRICK KIT 15-02-00121 L H BLOWER WITH MOTOR 05-02-00313 SIT VALVE NAT. GAS 65-06-00125 BLACK PAINT - 12 OZ. SPRAY CAN HA-30-00470 PILOT ASSY. LPG 65-06-00455 KEL-KEM GLASS CLEANER/POLISH 85-03-01115 DXV35 TIMBERFIRE Page 77...
  • Page 78 Convection Air Blower System Parts Item 1 15-02-00120 BLOWER, RH Item 2 15-02-00121 BLOWER, LH Figure 6-3 DXV35 TIMBERFIRE BLOWER ASSEMBLIES Valve Assembly Replacement Parts Item 1 65-14-00030 NG Orifice, #30 Item 2 05-04-00035 Pilot Assembly, 3-way hood Item 3...
  • Page 79 The glass frame assembly and its individual components are available through Johnson Gas Appliance Company. Contact your dealer for more detailed ordering information. GLASS FRAME ASSEMBLY REPLACEMENT PARTS LIST PART NUMBER DESCRIPTION ITEM FRAME, GLASS, DXV35 TIMBERFIRE HA-29-00522 GASKET, TADPOLE, 5 /8” BULB, 3/4” TAIL, 110” 65-02-00103 65-06-00463 GLASS, CERAMIC, DXV35 TIMBERFIRE...

  • Page 80: Checklist

    ❑ Burner flames are “stable” and are not “lifting” off burner. ❑ Inform owner that an initial curing step is required. Read and follow Mendota Fireplace and Insert Curing Instructions (found on unit and in owner’s manual). Smoke will emit during initial curing step.

  • Page 81: Arranty Policy Statement

    7.2 WARRANTY POLICY STATEMENT Mendota Fireplace, a division of Johnson Gas Appliance Company, extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below.

  • Page 82: Onditions

    Owner accepts that this appliance requires close monitoring of children and vulnerable individuals who are in the vicinity of this appliance when it is in operation. Mendota does not assume or accept any liability claims for burns or other physical or material damages resulting from touching hot glass surface and hot metal surfaces that are part of this appliance or other adjacent object such as hearth pads and mantels that may heat up during operation of this appliance.
  • Page 83 How to Obtain Warranty Service If you discover a problem that you believe to be covered by the warranty, you must report to your Mendota Dealer within 30 days, with proof of purchase, purchase date, model name and serial number.
  • Page 84 Owner Registration After installation, Mendota fireplace owners must register with Mendota to qualify for the Lifetime Limited Warranty within 30 days. Product registration will activate your Lifetime Limited Warranty. Owners should complete the forms available at: mendotahearth.com/warranty Note: Your Mendota dealer can assist with warranty applications and information.
  • Page 86 Johnson Gas Appliance Company 520 E Avenue NW Cedar Rapids, Iowa 52405 Mendota Warranty Registration...
