6.10

The wheels

At your wheelchair there are front and rear wheels mounted. These should be checked regularly for wear.
6.10.1

The front wheels

The front wheels of the wheelchair are 8" and, are fastened by means of a front fork to the frame of the wheelchair
(photo 35). The front wheels are important when you want to steer the wheelchair in the right direction. When
the steering is not going smoothly or the front wheels will vibrate if the front wheels are not properly set and / or
adjusted.
6.10.2

The rear wheels

The rear wheels of the chair have a 24 "PU tyre (photo 36). These tyres are puncture proof. The rear wheels have
handrims which enable you to propel the wheelchair. Furthermore, the rear wheels have a quick-release system.
This makes them easy to remove, simply by pressing the black button (picture 37) and then pulling removes the
rear wheels (photo 38).
EXCEL G-MODULAR | PHOTO 35
6.11

The seat

The seat (photo 39) of the wheelchair is equipped with nylon, wipe able material.
EXCEL G-MODULAR | PHOTO 39
