Unfolding The Wheelchair - Excel G-Modular User Manual

7.2

Unfolding the wheelchair

To unfold the wheelchair, please follow the following operations:
• Make sure the rear wheels are properly attached. You do this by pushing the black button on the rear wheel
(photo 47) and fix the rear wheel to the frame of the wheelchair (photo 48);
• Now, stand by the wheelchair and push the down seat on both sides at the point of the seat tubes (photo 49);
• To be sure that the wheelchair is correctly unfolded, stand beside the wheelchair and make sure the seat rails
as pushed down as far as they will go (photo 50);
• You can now fit the legrests. You can do this by going through the steps to remove the leg rests but in reverse
order.
• The leg supports will then engage into the receiving block with a click. (see photo 52);
• Also, don't forget your seat cushion. The wheelchair is now ready for use.
If you transport the wheelchair folded, you must make sure the wheelchair can't be dislodged whilst driving. This
can be done by correctly securing the chair.
EXCEL G-MODULAR | PHOTO 47
EXCEL G-MODULAR | PHOTO 51
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User Manual | Excel G-Modular
EXCEL G-MODULAR | PHOTO 48
EXCEL G-MODULAR | PHOTO 52
© 2015 Excel, part of Van Os Medical B.V.
EXCEL G-MODULAR | PHOTO 49
25
EXCEL G-MODULAR | PHOTO 50
