6.6

The leg rests

The legrests of the Excel G-Modular are both swing away and removable. To remove or swing away the legrests,
follow the following steps:
• In photo 23 you can see the footrests of the wheelchair;
• By pulling the orange lever (photo 24) upwards (photo 25), the leg rest can come in motion;
• On photo 26 you can see the leg rest can now be pulled out;
• If you want remove the leg rest, you have to lift it. You can lift the leg rest after you swung it as far round as
possible;
• To place the leg rest back you put the leg rest on the fixing point and swing the leg rest into place. When you
hear a 'click', the leg rest is securely attached.
EXCEL G-MODULAR | PHOTO 23
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User Manual | Excel G-Modular
EXCEL G-MODULAR | PHOTO 24
© 2015 Excel, part of Van Os Medical B.V.
EXCEL G-MODULAR | PHOTO 25
20
EXCEL G-MODULAR | PHOTO 26
