6.9

The stepper

The Excel G-Evolution is equipped with two steppers (photo 29). These can be used by the attendant to put extra

force when an increase should be undertaken with the wheelchair. However, you should be careful with the

steppers when you use them.

EXCEL G-EVOLUTION | PHOTO 29

6.10

At your wheelchair there are front and rear wheels mounted. These should be checked regularly for wear.

6.10.1

The front wheels of the wheelchair are 7" and fastened by means of a front fork to the frame of the wheelchair

(photo 30). The front wheels are important when you want to steer the wheelchair in the right direction. When the

steering is not going smoothly or the front wheels vibrate, the front wheels are not properly set and / or adjusted.

EXCEL G-EVOLUTION | PHOTO 30

6.10.2

The rear wheels of the wheelchair are 24" PU tires (photo 31). These tires are less prone to leak. On the rear

wheels are also hoops confirmed. These hoops enables you to propel the wheelchair. In addition, the rear wheel is

equipped with solid spokes. The rear wheels are removable by the quick-release system. This makes them easy to

take off. By pressing the black button (picture 32), you can remove the rear wheel (photo 33).

User manual | Excel G-Evolution

EXCEL G-EVOLUTION | PHOTO 31

EXCEL G-EVOLUTION | PHOTO 32

EXCEL G-EVOLUTION | PHOTO 33
