6.4

The backrest

The backrest of the Excel G-Modular (photo 19** Euro spec shown) the push handles of the half folding backrest
are incorporated within the tubes of the push handles. The backrest is not adjustable and not removable.
EXCEL G-MODULAR | PHOTO 19
6.5

The brakes

You can put your Excel G-Modular on the brakes. This is recommended when going in and / or going out of the
wheelchair, but also when you left parked, you can put the wheelchair on the brake. If you want to put the brakes
on the wheelchair, please follow the following steps.
• When sitting in the wheelchair and the wheelchair is not on the brake, you will see the situation as it is at
photo 20;
• You can use the brake lever to put the wheelchair on the brakes. By pushing the lever forward (away from
you) (photo 21), the wheelchair is put on the brakes (photo 22);
• If you are standing next to the wheelchair and you want to put the wheelchair on the brakes, you should
perform the same actions. Be careful here though that the wheelchair does not move.
EXCEL G-MODULAR | PHOTO 20
